Oracle X4-2B Installation Manual page 34

3. Insert the Server Module Into a Chassis
The following illustration shows rear panel features on the Sun Blade X4-2B.
Figure Legend
1
3
Caution –
or remove the server module from the chassis.
Open both of the server module ejector levers.
4
Position the server module vertically so that the ejectors are on the right.
Install the server module as follows:
5
a. Push the server module into the slot until the server module stops and is flush with the
chassis (see 1).
34 Sun Blade X4-2B Installation Guide • March 2014
Power connector
Rear cover (remove)
Drop hazard - Server modules can weigh up to 20 lbs (10kg). Use two hands to install
2 I/O Connector
4 USB internal ports 0, 1
