Oracle X4-2B Installation Manual page 30

Install Optional Components
Optional component
Multi-port cable
Software media
USB Stick
A USB flash stick with a standard USB 2.0 interface can be obtained from third-party sources.
To avoid protruding past the rear panel, the USB flash stick must be no larger than 2.7 mm wide
and 32.0 mm long, as shown in this illustration:
Caution –
Related Information
"Insert the Sun Blade X4-2B Server Module Into a Chassis" on page 33
■
▼
Verify Supported Components
Supported components and their part numbers are subject to change over time and without
notice.
To view the most up-to-date list of Sun Blade X4-2B supported components.
Go to https://support.oracle.com/handbook_private/.
1
Enter required Oracle web account information.
2
This site requires an Oracle web account to access.
Click the name and model of the server module (Sun Blade X4-2B).
3
30 Sun Blade X4-2B Installation Guide • March 2014
Description
Each Sun Blade 6000 series chassis is typically shipped with a multi-port cable
(dongle). Additional multi-port cables can be ordered. Multi-port cables are
listed as 3-Cable Dongle II (part number X4622A-N).
For information about ordering software media, see Getting Server Firmware and
Software Updates.
Physical damage hazard. Using a larger USB device could damage the USB port.
