4
BATTERY CHARGING
D Using the BC-197 to rapid charge the BP-264 or
BP-265
The BC-197 rapidly charges up to six battery packs.
Charging time for the BP-264: Approximately 2 hours
Charging time for the BP-265: Approximately 2.5 hours
The following additional item is required:
• An AC adapter (not supplied with some versions) or the DC pow-
er cable (OPC-656)

Battery pack

Status indicator
(each indicator independently functions)
29
Transceiver
Turn OFF the power
Charger adapters* are
installed in each slot.
*
The shape of charger adapter depends
on the version of the BC-197.
DC power cable (OPC-656)
(Connect to a DC power supply;
12 to 16 V/at least 7 A)
Red line : + Black line : _
AC adapter
(An AC adapter is
not supplied with
some versions.)
