- Page 1 INSTRUCTION MANUAL VHF DIGITAL/ANALOG TRANSCEIVER iF3200DEX Series UHF DIGITAL/ANALOG TRANSCEIVER iF4200DEX Series This device complies with Part 15 of the FCC Rules. Op- eration is subject to the condition that this device does not cause harmful interference. The photo shows the VHF transceiver.
-
Page 2: Explicit Definitions
FOREWORD READ ALL INSTRUCTIONS carefully and completely before using the transceiver. SAVE THIS INSTRUCTION MANUAL— This instruc- tion manual contains important operating instructions for the IC- F3203DEX VHF DIGITAL/ANALOG TRANSCEIVER and the IC- F4203DEX UHF DIGITAL/ANALOG TRANSCEIVER • This instruction manual includes some functions which are us- able only when they are preset by your dealer. -
Page 3: Voice Coding Technology
#5,870,405, #5,826,222, #5,754,974, #5,701,390, #5,715,365, #5,649,050, #5,630,011, #5,581,656, #5,517,511, #5,491,772, #5,247,579, #5,226,084 and #5,195,166. Icom, Icom Inc. and the Icom logo are registered trademarks of Icom Incorpo- rated (Japan) in Japan, the United States, the United Kingdom, Germany, France, Spain, Russia and/or other countries. -
Page 4: Precautions
Use and charge only specified Icom battery packs with Icom radios or Icom chargers. Only Icom battery packs are tested and approved for use with Icom radios or charged with Icom chargers. Using third-party or counterfeit battery packs or chargers may cause smoke, fire, or cause the battery to burst. - Page 5 DO NOT push [PTT] when you do not actually intend to transmit. DO NOT use or place the transceiver in direct sunlight or in areas with temperatures below–20°C (–4°F) or above +55°C (+131°F). DO NOT modify the transceiver. The specifications may change and then not comply with the requirements of a corresponded regulation.
-
Page 6: Table Of Contents
TABLE OF CONTENTS FOREWORD ..................i EXPLICIT DEFINITIONS ..............i VOICE CODING TECHNOLOGY ..........ii PRECAUTIONS ................iii TABLE OF CONTENTS ..............v 1 ACCESSORIES ..............1–4 Supplied accessories ............1 ■ Accessory attachments ............1 ■ 2 PANEL DESCRIPTION ............5–13 Front, top and side panels ............5 ■... - Page 7 4 dPMR OPERATION ............27–32 dPMR operation ..............27 ■ Receiving a call ..............27 ■ Transmitting a call ...............30 ■ Status message transmission ..........32 ■ Scrambler function ..............32 ■ 5 BATTERY CHARGING .............33–38 Caution ................33 ■ Battery charger ..............37 ■ 6 SPEAKER MICROPHONE ..........39–40 Optional HM-203EX description .........39 ■...
-
Page 8: Accessories
ACCESSORIES Supplied accessories ■ The following accessories are supplied with the transceiver. Battery pack* Flexible antenna (This illustration is for the VHF type.) Battery charger* AC adapter* Belt clip* Connector cover (with screws) * Not supplied, or the shape is different, depending on the version. Accessory attachments ■... - Page 9 ACCESSORIES Belt clip To attach the belt clip: ➥ Slide the belt clip in the direction of the arrow until the belt clip locks in place, and makes a ‘click’ sound. Belt clip To detach the belt clip: Remove the battery pack from the transceiver, if it is attached. (p.
- Page 10 ACCESSORIES Battery pack To attach the battery pack: Slide the battery pack on the back of the transceiver in the direction of the arrow (q), then lock it with the battery release button. • Slide the battery pack until the battery release button makes a ‘click’ sound.
-
Page 11: Accessories
ACCESSORIES Connector cover Attach the connector cover when optional equipment is not used. To attach the connector cover: To detach the connector cover: Attach the cover to the multi q Remove the screw with a connector. phillips screwdriver. Tighten the screw. w Detach the cover to connect the optional equipment. -
Page 12: Panel Description
PANEL DESCRIPTION Front, top and side panels ■ ROTARY SELECTOR VOLUME ANTENNA CONTROL CONNECTOR LED INDICATOR UPPER KEY Speaker LOWER KEY MULTI CONNECTOR PTT SWITCH Microphone q ROTARY SELECTOR Rotate to select the preprogrammed memory channels or scan lists, depending on the preprogramming. w VOLUME CONTROL [VOL] Rotate to turn the power ON or OFF, and adjust the audio level. - Page 13 PANEL DESCRIPTION e LED INDICATOR (pp. 7–9) Lights red while transmitting. ➥ Lights green while receiving a signal, or when the squelch ➥ is open. Lights/blinks orange when the matched 2/5-tone code is re- ➥ ceived, depending on the presetting. r MULTI CONNECTOR Connect optional equipment.
-
Page 14: Led Indicator
PANEL DESCRIPTION LED indicator ■ The LED indicator indicates the status of various parameters of the transceiver as follows; (Reference: R=Red, G=Green, O=Orange) • TX: Lights Red while transmitting. • RX busy: On an analog channel, lights Green when in the noise squelch opens. - Page 15 PANEL DESCRIPTION • Call error: Blinks slowly when your call failed, or was refused. • Audible: Blinks slowly after a return signal is received when in the Audible mode*. * Mute is released. (Received signal will be heard.) • Fast/Slow scan or voting: Blinks when scanning for a channel to search for a signal or a repeater to register on.
- Page 16 PANEL DESCRIPTION LED indicator (Continued) ■ • Channel Error: Blinks when a non-programmed channel is selected. R O R O R O R O R O R O R O R O • Power ON: Blinks at transceiver startup. R O G R O G •...
-
Page 17: Programmable Function Keys
Programmable function keys ■ The following functions can be assigned to the [Upper] and [Lower] programmable function keys. Consult your Icom dealer or system operator for details concerning your transceiver’s programming. SCAN Push to start and cancel scanning. • When the scan started with the Power ON Scan or Auto Scan func- tion, push to pause the scan. - Page 18 PANEL DESCRIPTION Programmed function keys (Continued) ■ MONITOR, MONITOR (AUDIBLE) Push to turn the CTCSS (DTCS) or 2/5-tone squelch Mute ON ➥ or OFF. • Only during LMR operation, push to open any squelch func- tions, or deactivate any mute functions. •...
- Page 19 PANEL DESCRIPTION RE-DIAL Push to transmit the last-transmitted DTMF code. NOTE: TX memories are cleared after turning OFF the transceiver. WIDE/NARROW Push to toggle the IF bandwidth between Wide, Mid* or Narrow. * Depending on the presetting, the Mid channel width may not be selectable.
- Page 20 PANEL DESCRIPTION Programmed function keys (Continued) ■ SIREN Hold down for 1 second to emit a siren sound. This function can be used for situations other than an emergency alert, such as a security alarm for example. The transceiver emits the siren sound until the power is turned OFF.
-
Page 21: Basic Operation
BASIC OPERATION Turning ON the power ■ Prior to using the transceiver for the first time, the battery pack must be fully charged for optimum life and operation. (p. 33) [VOL] Rotate [VOL] to turn ON the power. ➥... -
Page 22: Channel Selection
BASIC OPERATION Channel selection ■ Several types of channel selections are available. Methods may dif- fer, depending on the presetting. To select a desired operating channel, do one of the following. • Rotate [ROTARY SELECTOR]. • Push one of the memory channel keys, [MR-CH 1] to [MR-CH 4]. •... -
Page 23: Call Procedure
BASIC OPERATION Call procedure ■ When your system employs tone signalling (excluding CTCSS and DTCS), the tone call procedure may be necessary prior to voice transmission. The tone signalling that is employed in the transceiver may be a selective calling system, which allows you to call only specific station(s), and prevents unwanted stations from contacting you. -
Page 24: Receiving And Transmitting
BASIC OPERATION Receiving and transmitting ■ CAUTION: Transmitting without an antenna will damage the transceiver. See page 1 for antenna attachment. Receiving: Rotate [VOL] to turn ON the power. Rotate [ROTARY SELECTOR], or push one of the memory channel keys, [MR-CH 1] to [MR-CH 4], to select a channel. When receiving a call, adjust the audio output to a comfortable listening level. -
Page 25: D Transmitting Notes
BASIC OPERATION Transmitting notes • Transmit inhibit function The transceiver has several inhibit functions, which restrict trans- mission under the following conditions: - The channel is muted. (PMR operation only) - The channel is busy. - A signal with an unmatched (or matched) CTCSS (or DTCS) tone is received. -
Page 26: D Dtmf Transmission
BASIC OPERATION DTMF transmission If the transceiver has [DTMF Autodial] assigned to it, the automatic DTMF transmission function is usable. Push [DTMF Autodial] to transmit the DTMF code. ➥ Receiving a Stun, Kill and Revive command The dispatcher can send a signal that will stun, kill or revive your transceiver. -
Page 27: Setting The Microphone Gain
BASIC OPERATION Setting the microphone gain ■ Adjusts the microphone gain. Rotate [VOL] to turn the trans- [ROTARY SELECTOR] ceiver power OFF. [VOL] Set [ROTARY SELECTOR] to Channel 16. While holding down [Upper], ro- tate [VOL] to turn ON the power and enter the microphone gain [Upper] adjustment mode. -
Page 28: Setting The Squelch Level
BASIC OPERATION Setting the squelch level ■ The squelch circuit mutes the received audio signal, depending on the signal strength. [ROTARY SELECTOR] Rotate [VOL] to turn OFF the transceiver power. [VOL] Set [ROTARY SELECTOR] to any channel other than Chan- nel 16. -
Page 29: Setting The Beep Level
BASIC OPERATION Setting the Beep level ■ The beep function can be turned ON or OFF, and its level can be adjusted between 1 and 5, or 1 (linked) and 5 (linked). When a Linked option is selected, the beep level is adjustable with [VOL]. [ROTARY SELECTOR] Rotate [VOL] to turn OFF the transceiver power. -
Page 30: Setting The Ringer Level
BASIC OPERATION Setting the Ringer level ■ The Ringer level can be adjusted between 1 and 5, or 1 (Linked) and 5 (Linked). When a Linked option is selected, the Ringer level is adjustable with [VOL]. Rotate [VOL] to turn OFF the [ROTARY SELECTOR] transceiver power. -
Page 31: Output Power Level Selection
BASIC OPERATION Output power level selection ■ If the transceiver has [High/Low] assigned to it, the transmit output power level can be selected, depending on the presetting. When the battery voltage drops to a low power level and the LED indicator status is “Low Battery 2,”... -
Page 32: Lone Worker Emergency Call
BASIC OPERATION Lone Worker Emergency Call ■ When the Lone Worker function is turned ON, and no operation is performed for the specified time period*, the transceiver enters the emergency mode, and then the countdown for the emergency call transmission starts. After the specified time period* has passed, an emergency call is automatically transmitted once, or repeatedly*. -
Page 33: Emergency Call
BASIC OPERATION Emergency Call ■ When [Emergency] is held down for the specified time period*, the emergency signal is transmitted once, or repeatedly, on the speci- fied emergency channel. * Depending on the presetting. Ask your dealer for details. A repeat emergency signal is automatically transmitted until you turn OFF the power. -
Page 34: Dpmr Operation
dPMR OPERATION dPMR operation ■ The transceiver providing digital Private Mobile Radio (dPMR) operation meets the 6.25 kHz bandwidth requirements for narrow band operation. This increases the efficiency of channel allocation and use of the spectrum. NOTE: During dPMR operation, BIIS 1200 operation is dis- abled. -
Page 35: D Receiving A Group Call
dPMR OPERATION Receiving a Group call When a Group call is received: • The LED indicator blinks orange. • Beeps sound and the mute is released. Hold down [PTT], then speak into the microphone. NOTE: Only one station is allowed to speak at the same time. - Page 36 dPMR OPERATION Receiving a call (Continued) ■ Receiving a Status Polling call If a Status Polling call is received, the transceiver will automatically transmit its current status.* Receiving an Ambience Listening call If an Individual call with an Ambience Listening command is re- ceived from a specified station, the transceiver will automatically transmit its microphone audio.* *Depending on the presetting.
-
Page 37: Transmitting A Call
dPMR OPERATION Transmitting a call ■ dPMR operation allows you to make a call to a specific station (In- dividual call) or to a particular group (Talkgroup call). Other digital mode transceivers on the channel will not receive a call that does not match their individual or talkgroup ID and/or CC. - Page 38 dPMR OPERATION Transmitting a call (Continued) ■ Transmitting an Emergency call When [Emergency] is held down for the specified time period, the emergency signal (digital command) is transmitted once or repeat- edly* on the specified emergency channel. When no emergency channel is specified, the signal is transmitted on the operating channel.
-
Page 39: Status Message Transmission
dPMR OPERATION Status message transmission ■ The status message can automatically be transmitted. The status message is transmitted when the transceiver is turned ON or OFF. - Select a status message to be transmitted in ‘Power ON Status’ or ‘Power OFF Status’ items, respectively. - Select a target station ID in ‘Power Status ID’. -
Page 40: Battery Charging
BATTERY CHARGING Caution ■ Misuse of Li-ion batteries may result in the following hazards: smoke, fire, or the battery may rupture. Misuse can also cause damage to the battery or degradation of battery performance. R DANGER! NEVER short terminals (or charging terminals) of the battery pack. - Page 41 R WARNING! Immediately stop using the battery if it emits an ab- normal odor, heats up, or is discolored or deformed. If any of these conditions occur, contact your Icom dealer or distributor. R WARNING! Immediately wash, using clean water, any part of the body that comes into contact with fluid from inside the battery.
- Page 42 BATTERY CHARGING CAUTION: Shorter battery life could occur if the battery is left fully charged, completely discharged, or in an excessive temperature environment (above +50˚C; +122°F) for an extended period of time. If the battery must be left unused for a long time, it must be de- tached from the radio after discharging.
-
Page 43: D Charging Caution
CAUTION: DO NOT charge the battery outside of the specified temperature range: BC-212EX (+10˚C to +40˚C; +50°F to +104°F). Icom recommends charging the battery at +20˚C (+68°F). The bat- tery may heat up or rupture if charged out of the specified tempera- ture range. -
Page 44: Battery Charger
BATTERY CHARGING Battery charger ■ Using the BC-212EX to rapid charge the BP-277EX The BC-212EX rapidly charges the Li-ion battery pack. Charging time: Approximately 2.5 hours (for the BP-277EX) Following item is additionally required: • An AC adapter (not supplied with some versions) Transceiver Turn OFF the power Battery pack... - Page 45 BATTERY CHARGING IMPORTANT: Ensure the grooves on the battery pack are correctly aligned with the guide rails inside the charger. Grooves Guide rail...
-
Page 46: Speaker Microphone
SPEAKER MICROPHONE Optional HM-203EX description ■ Microphone PTT SWITCH Hold down to Speaker transmit, release to receive. Belt clip Turn OFF the trans- ceiver power when connecting or dis- connecting the mi- crophone. NEVER immerse the connector in water. If the connector becomes wet, be sure to dry it BEFORE connecting it to the transceiver. -
Page 47: To Attach
SPEAKER MICROPHONE To attach ■ BE SURE to turn OFF the power before attaching. Attach the connector of the speaker microphone into the multi con- nector on the transceiver, and tighten the screw. Turn OFF the power CAUTION: Attach the multi connector snugly, but do not overtighten. -
Page 48: Options
OPTIONS BATTERY PACK • BP-277EX ion battery pack Voltage: 7.4 V Capacity: 1800 mAh (min.) 1900 mAh (typ.) Battery life Digital mode Analog mode Digital mode Analog mode 21.5 hrs. 21 hrs. 19 hrs. * When the power save function is turned ON, and the operating time is calculated under the following conditions;... - Page 49 Approved Icom optional equipment is designed for optimal performance when used with an Icom transceiver. Icom is not responsible for the destruction or damage to an Icom trans- ceiver in the event the Icom transceiver is used with equipment that is not manufactured or approved by Icom.
-
Page 50: Safety Training Information
This radio has been tested and complies with the FCC and IC RF exposure limits for “Occupational Use Only”. In addition, your Icom radio complies with the following Standards and Guidelines with regard to RF energy and electromagnetic energy levels and evaluation of such levels for exposure to humans: •... - Page 51 “PTT” switch or VOX function. • ALWAYS keep the antenna at least 2.5 cm (1 inch) away from the body when transmitting and only use the Icom belt-clip which is listed on page 41 when attaching the radio to your belt, etc., to ensure FCC and IC RF exposure compliance requirements are not exceeded.
- Page 52 Cet appareil a été évalué et jugé conforme, aux limites d’exposition aux RF de la FCC et d’IC, pour une «utilisation grand public». En outre, votre radio Icom satisfait les normes et directives qui suivent en matière de niveaux d’énergie et d’énergie électromagnétique de RF et d’évalua- tion de tels niveaux en ce qui concerne l’exposition humaine:...
- Page 53 RF établies par la FCC et d’IC. Interférence électromagnétique et compatibilité En mode de transmission, votre radio Icom produit de l’énergie de RF qui peut provoquer des interférences avec d’autres appareils ou sys- tèmes.
-
Page 54: Fcc Information
CAUTION: Changes or modifications to this device, not expressly approved by Icom Inc., could void your authority to operate this transceiver under FCC regulations. - Page 55 MEMO...
- Page 56 A-7100D-1EX Printed in Japan © 2013 Icom Inc. 1-1-32 Kamiminami, Hirano-ku, Osaka 547-0003, Japan Printed on recycled paper with soy ink.
