3
BATTERY PACKS
■ Battery pack replacement
➥ Before replacing the battery
pack, push [PWR] for 1 sec.
to turn the power OFF.
➥ Slide the battery release forward, then pull the battery pack
upward with the transceiver facing away from you.
8
D D BATTERY PACKS
Battery
pack
BP-208N
BP-209N
BP-210N
BP-211N
PWR
BP-222N
Push
for 1 sec.
1
*
Operating periods are calculated under the following conditions;
Tx : Rx : standby =1 : 1 : 8, power save function: auto setting is
activated
2
*
Operating period depends on the alkaline cells used.
Voltage
Capacity
Battery life*
Battery case for AA
(LR6)×6 alkaline
7.2 V
1100 mAh
3 hrs. 20 min.
7.2 V
1650 mAh
7.4 V
1800 mAh
6 hrs. 10 min.
7.2 V
600 mAh
2 hrs. 15 min.
1
—*
2
6 hrs.
