5. Commands – Quick summary
Router Status commands
View product type
View serial number
View Firmware version of the CPU
View installed controllers' firmware
View device's temperature
View CPU firmware compile time
View installed I/O boards
System commands
Query current control protocol
Change RS-232 baud rate
Query RS-232 baud rate
Reload factory defaults
Set the RS232 operation mode
Query the RS232 operation mode
Count HDCP keys
Clear HDCP key cache
Restart matrix router
View error list
Configure remote alerts
Query level of remote alerts
Set the priority settings
Query the priority settings
EDID router commands
Save EDID to user memory (Learn EDID)
View emulated EDIDs on all inputs
Watch EDID validity table
View EDID header
Download EDID content from the router
Upload EDID content to the router
Delete EDID from memory
Page 40 / 43
Section
Command
4.3.1
{I}
4.3.2
{S}
4.3.3
{F}
4.3.4
{FC}
4.3.5
{ST}
4.3.6
{CT}
4.3.7
{IS}
Section
Command
4.4.1
{P_?}
4.4.2
{RS232BAUD=<rate>}
4.4.3
{RS232BAUD=?}
{FACTORY=<f1>;<f2>;...;<fx>}
4.4.4
4.4.5
{RS232=<mode>}
4.4.6
{RS232=?}
4.4.7
{:HDCPTEST<in>@<num>}
4.4.8
{:HDCPRESET}
4.4.9
{RST}
4.4.10
{ELIST=?}
4.4.11
{ELEVELSEND#<p>=<0>;<1>;
<2>;<3>;<4>}
4.4.12
{ELEVELSEND#<p>=?}
4.4.13
{VIDEOPRIORITY=<pmode>}
4.4.14
{VIDEOPRIORITY=?}
Section
Command
4.5.1
{<loc1>:<loc2>}
4.5.2
{VEDID}
4.5.3
{WV<type>}
4.5.4
{WH<loc>}
4.5.5
{WE<loc>}
4.5.6
{WL#<loc>}
4.5.7
{DE<loc>}
Section 5. Commands – Quick summary
