Input settings
Set input port properties
Query input port properties
Set analog timing properties
Query analog timing properties
Reset analog timing properties
Set analog color properties
Save analog color properties
Query analog color properties
Reset analog color properties
Set analog input audio parameters
Query analog input audio properties
Set the color of no sync picture
Query the color of no sync picture
Query timings of the incoming signal
Save preset
Delete preset
Delete all presets
Clone preset
List presets
Delete preset from all input ports
Output settings
Set output video properties
Query output video properties
Section 5. Commands – Quick summary
Programmer's Reference Manual
Section Command
4.8.1 {:DVII#<in>@<S/A>I=<VIDEO>;
<X1>;<X2>;<HDCP>}
4.8.2
{:DVII#<in>@<S/A>I=?}
4.8.3 {:ANALOG#<in>@<S/A>I=<PHS>
;<FHS>;<HS>;<VS>;<HP>;<VP>;}
4.8.4 {:ANALOG#<in>@<S/A>I=?}
4.8.5 {:ANALOG#<in>@<S/A>I=
RESET}
4.8.6 {:PICTURE#<in>@<S/A>I=
<DF_CHA>;<DF_CHB>;
<DF_CHC>;<G_CHA>;<G_CHB>;
<G_CHC>;<O_CHA>;<O_CHB>;
<O_CHC>;<CONT>;<SAT>;
<BRIGHT>;<HUE>;)
4.8.7 {:PICTURE#<in>@<S/A>I=SAVE}
4.8.8
{:PICTURE#<in>@<S/A>I=?}
4.8.9 {:PICTURE#<in>@<S/A>I=
FACTORY}
4.8.10 {:AUDIN#<in>@<S/A>I=<VOL>;
<BAL>;<GAIN>;<PHS>;<DCF>}
4.8.11 {:AUDIN#<in>@<S/A>I=?}
4.8.12 {:SETBG#<in>@<S/A>I=
<RED>;<GREEN>;<BLUE>;}
4.8.13 {:SETBG#<in>@<S/A>I=?}
4.8.14 {GETTIMINGS#<in>@<S/A>=?}
4.8.15 {:AF#<in>@SI=<IPS>}
4.8.16 {:AF#<in>@SI=DEL;<PID>}
4.8.17 {:AF#<in>@SI=DEL;255}
4.8.18 {:AF#<in>@SI=CL;<PID>}
4.8.19 {:AF#<in>@<S/A>I=LIST}
4.8.20
{:AF#<in>@SI=DELALL;<PID>}
Section Command
4.9.1 {:HDMI#<out>@<S/A>O=
<MODE>;<CSPAC>;<CRANG>;
<SUBS>;<HDCP>;}
4.9.2
{:HDMI#<out>@<S/A>O=?}
