4.4.9. Restart matrix router

Description: The extender can be restarted without unplugging power.
Command {RST}
Response (Booting...)CrLf
Legend:
Explanation: The extender reboots and sends a message when it is ready.
Info: The response can be seen only if the connection to the extender is still alive.

4.4.10. View error list

Description: Shows the basic error list since last boot up.
Command {ELIST=?}
Response (ELIST#<num>●<elevel>●<code>
Legend:
Explanation: There are no errors only standard notices that occur on boot up.
Info: The error list can contain NOTICEs and WARNINGs under normal operation. These
entries do not mean that there is any problem with the matrix!
Section 4. Programmers reference
Format
(<name>●Ready!)CrLf
<name> is the type of the extender
Format
●<param>●<occ>)CrLf
...
(ELIST#<num>●<elevel>●<code>
●<param>●<occ>)CrLf
<num>: line number
<elevel>: NOTICE =
WARNING = Possible problem without influencing normal
MATTER =
ERROR =
FATAL =
<code>: short name for type of log entry
<param>: technical parameter
<occ>: occurrence number for this type of log entry
Programmer's Reference Manual
→ {rst}
←
(Booting...)CrLf
←
(UMX-TP-TX100R Ready!)
→ {elist=?}
←
(ELIST#1 Notice BOOT
p:6 o:1)CrLf
...
←
(ELIST#2 Notice READY
p:0 o:1)CrLf
Not an error. Initialization information.
operation.
Problem that may lead to further errors.
Serious error. Must report to support.
Fatal error. Normal operation is not possible.
UMX-TP-TX100R
Example
Example
