4.8.3. Set analog timing properties

Description: This command changes the setup of the analog timing data.
Command {:ANALOG#<in>@<S/A>I=
Response (DVII#<in>@<S/A>I=
Legend:
Info: The following parameters cannot be set, they only appear in response.

4.8.4. Query analog timing properties

Description: Check analog timing data of the input ports.
Command {:ANALOG#<in>@<S/A>I=?}
Response (ANALOG#<in>@<S/A>I=
Legend:

4.8.5. Reset analog timing properties

Description: This command resets the analog timing properties.
Command {:ANALOG#<in>@<S/A>I=RESET}
Response
Legend:
Section 4. Programmers reference
Format
<PHS>;<FHS>;
<HS>;<VS>;
<HP>;<VP>;}
<PHS><FHS>;
<HS>;<VS>;
<HP>;<VP>;
<LCF>;
<FORM>;<VSP>;<HSP>;
<FPS>;)CrLf
<S/A>: Affected ports:
S = single selected input
A = all inputs
<PHS> Phase
<FHS> Full Horizontal Size
<HS> Horizontal Size
<VS> Vertical Size
<HP> Horizontal Position
<VP> Vertical Position
<LCF> Full Vertical Size (Line Count per Field)
<FORM> Format: Progressive or Interlaced
<VSP> Vertical Sync. Polarity
<HSP> Horizontal Sync. Polarity
<FPS> Frame Per Sec in Hz
Format
<PHS>;<FHS>;
<HS>;<VS>;
<HP>;<VP>;<LCF>;
<FORM>;<VSP>;<HSP>;<FPS>)CrLf
Please read section 4.8.3
Format
(ANALOG#<in>@<S/A>I=
<PHS>;<FHS>;
<HS>;<VS>;
<HP>;<VP>;<LCF>;
<FORM>;<VSP>;<HSP>;<FPS>)CrLf
Please read section 4.8.3
Programmer's Reference Manual
Example
→ {:analog#2@si=
10;2160;
1600;1200;
455;41;}
← (ANALOG#2@SI=
10;2160;
1600;1200;
455;41;
1124;
P;-;-;
50;)CrLf
→ {:analog#2@si=?}
← (ANALOG#2@SI=
0;2160;
1600;1200;
455;41;1242;
P;+;+;60;)CrLf
on page 31.
→ {:analog#2@si=reset}
← (ANALOG#1@SI=
0;2160;
1600;1200;
455;41;1242;
P;+;+;60;)CrLf
on page 31.
UMX-TP-TX100R
Example
Example
Page 31 / 43
