4.8.20. Delete preset from all input ports

Description: This command deletes the desired from all analog input ports.
Command {:AF#<in>@SI=DELALL;<PID>}
Response (AF DELETED)CrLf
Legend:
Explanation: This command is reserved for compatibility reasons.
4.9.

Output properties

The following commands are setting up the properties of the output ports. If only one or a
few parameters have to be modified, the protocol enables to mask the other parameters,
so they can stay untouched. To mask a parameter use "x" or "X" as its value.
Example:

4.9.1. Set output video properties

Description: This command is for configuring output port settings.
Command
Response
Legend for command:
Legend for response:
Section 4. Programmers reference
Format
<PID> Preset ID number
{:HDMI#1@SO=H;x;x;x;1;} Set output port no. 2 to HDMI 24 bit.
Format
{:HDMI#<out>@<S/A>O=
<MODE>;
<CSPAC>;
<CRANG>;
<SUBS>;
<HDCP>;}
(HDMI#<out>@<S/A>O=
G<CON><MODE><SIG>
<HDCP><HPD>;
O<MODE><CSPAC>
<CRANG>;<SUBS> <HDCP>)
M<HSUP><AUTH><REP>
<YUV4><YUV2>
<AUD><PCM><DC>CrLf
<S/A>: Affected ports:
S = single-selected output
A = all outputs
<MODE>: Output signal mode:
A = Automatic (this setting gives a response as D/H/1/2),
D = DVI,
H = HDMI 24bit,
1 = HDMI 30bit deepcolor,
2 = HDMI 36bit deepcolor.
<CSPAC>: Reserved for legacy reasons. Set 'X' here.
<CRANG>: Reserved for legacy reasons. Set 'X' here.
Reserved for legacy reasons. Set 'X' here.
<SUBS>:
<HDCP>: HDCP encryption:
A = automatic,
1 = always use.
G block: General status information
<CON>: Connection sense:
0 = There is no attached sink device,
1 = Sink device attached (termination is present)
Programmer's Reference Manual
Example
→ {:af#2@si=delall;1}
← (AF DELETED)CrLf
Example
→ {:HDMI#1@SO=H;x;x;x;1;}
← (HDMI#2@SO=G0H100;OHAAA1;)CrLf
UMX-TP-TX100R
Page 37 / 43
