2.2.

Factory EDID list

3. Operation modes

There are two kinds of operations for the unit regarding the serial port: you can control
the unit or use the bidirectional serial link through the DDC CAT cable with a compatible
HDMI-TP receiver.
1. In the first case the CPU in the transmitter can receive commands and send
Page 12 / 43
Memory
F01
F02
F03
F04
F05
F06
F07
F08
F09
F10
Table 2-1. Factory preset EDID list
responses either to and from the own serial port or to and from the serial port on the
receiver unit through the DDC line (2
DSUB connector
Pin 2: DSUB TX OUT
Pin 3: DSUB RX IN
Figure 3-1. UMX-TP-TX100R in CONTROL mode
Resolution
Universal_HDMI_DC
1024 x 768 @ 60.0 Hz
1280 x 720 @ 60.0 Hz
1920 x 1080 @ 60.0 Hz
1920 x 1200 @ 59.55 Hz
Universal_Analog
1024 x 768 @ 60.0 Hz
1280 x 720 @ 60.0 Hz
1920 x 1080 @ 60.0 Hz
1920 x 1200 @ 59.55 Hz
nd
CAT cable).
CPU
Type
HDMI
DVI
HDMI
HDMI
DVI
Analog
Analog
Analog
Analog
Analog
TP connector
Pin 6: TP RX IN
Pin 3: TP TX OUT
Section 3. Operation modes
