Source dependent parameters:
Analog signal properties are displayed, when <SOURCE> = R / C:
Digital signal properties are displayed, when <SOURCE> = H / D:
If HDMI signal present <SOURCE> = H, there are more HDMI specific parameters:
Section 4. Programmers reference
<ATIM1> Analog timing1:
0 = SMTPE standard
1 = User saved preset
2 = EDID detailed timing
3 = Factory preset
4 = GTF formula
5 = User modified (not saved)
<ATIM2> Analog timing2: (depending on <ATIM1>)
<ATIM1> = 0 -> SMTPE record number
<ATIM1> = 1 -> User preset number
<ATIM1> = 2 -> Detailed timing number
<ATIM1> = 3 -> Factory preset number
<ATIM1> = 4 -> Fixed zero.
<ARES> Resolution string. (example: 1600x1200p60)
<DCS> 2 byte hexadecimal number:
bit 0 = 1:
bit 1 = 1:
bit 2 = 1:
bit 0&1&2 =0: Color depth: 24 bit/pixel
bit 4:
bit 5:
<DRES> Incoming resolution string. (example: 1600x1200p60)
<HAUDIO> HDMI Audio properties:
0 = no audio
P = 2 channel stereo (L-PCM)
M = Multichannel-PCM (M-PCM)
S = Compressed audio
H = HBR audio
D = DST audio (not supported)
E = DSD audio (not supported)
<HASAMP> If <HAUDIO> not S or H: HDMI audio sample rate in kHz.
<HAUDIO> = S (Compressed) multiply by 32,
<HAUDIO> = H (HBR) multiply by 4
32 32
44 44,1
48 48
88 88,2
96 96
176 176,4
192 192
<HCH> Contains CEA-861 compatible channel assignment,
if M-PCM signal present:
0x00
0x01
0x02
0x03
0x04
0x05
0x06
0x07
0x08
0x09
0x0A
Programmer's Reference Manual
Color depth: 30 bit/pixel (not supported)
Color depth: 36 bit/pixel
Color depth: 48 bit/pixel (not supported)
Color space: YCbCr422
Color space: YCbCr444
kHz
kHz
kHz
kHz
kHz
kHz
kHz
- - - -
- - - -
- - - -
- - - -
- - - RC
- - - RC
- - - RC
- - - RC
- - RR RL
- - RR RL
- - RR RL
UMX-TP-TX100R
- - FR FL
- LFE FR FL
FC - FR FL
FC LFE FR FL
- - FR FL
- LFE FR FL
FC - FR FL
FC LFE FR FL
- - FR FL
- LFE FR FL
FC - FR FL
