4.8.11. Query analog input audio properties

Description: This command reads the setup of the ADC on the audio board.
Command {:AUDIN#<in>@<S/A>I=?}
Response (:AUDIN#<in>@<S/A>I=<VOL>;
Legend:

4.8.12. Set the color of no sync picture

Description: If there is no incoming video signal the device gives a monochrome
640x480p60 picture to the output. This command sets the color of the no sync picture
with an RGB value on the active input port.
Command {:SETBG#<in>@<S/A>I=
Response (SETBG#1@SI=
Legend:
Explanation: The example shows how to set yellow colored monochrome no sync
Info: Setting of the color of no sync picture is available only on the selected active input.

4.8.13. Query the color of no sync picture

Description: This command reads the RGB color code of the no sync picture on the
active input port.
Command {:SETBG#<in>@<S/A>I=?}
Response (SETBG#1@SI=
Legend:
Explanation: The no sync picture color is the (255, 255, 0) RGB coded yellow on the
Info: Querying of the color of no sync picture is available only on the selected active input.
Page 34 / 43
Format
<BAL>;<GAIN>;<PHS>;<DCF>)CrLf
Please read section 4.8.10
Format
<RED>;<GREEN>;<BLUE>;}
<RED>;<GREEN>;<BLUE>;)CrLf
<S/A>: Affected ports:
S = single selected input
A = all outputs
<RED> Red component of RGB value.
<GREEN> Green component of RGB value.
<BLUE> Blue component of RGB value.
picture on the HDMI input port.
Format
<RED>;<GREEN>;<BLUE>;)CrLf
Please read section 4.8.12
HDMI input port.
→ {:audin#2@si=?}
← (AUDIN#2@SI=0;50;0;0;0;)CrLf
on page 33.
→ {:setbg#1@si=255;255;0;}
← (SETBG#1@SI=255;255;0;)CrLf
→ {:SETBG#1@SI=?}
← (SETBG#1@SI=255;255;0;)CrLf
on page 34.
Section 4. Programmers reference
Example
Example
Example
