4.3.6. View CPU firmware compile time

Description: Shows the CPU firmware compile time.
Command {CT}
Response (Compiled:<DATE>●<TIME>●
Legend:
Explanation: The firmware was made in 21.09.2012, 14:06:36 and the identification
number of the firmware is 4427.

4.3.7. View installed I/O boards

Description: Shows the hardware name and revision of the installed cards. The number
of responses varies regarding the frame size (number of slots).
Command {IS}
Response (SL#●0●<MB_DESC>)CrLf
Legend:
Explanation: The extender reports that it has one motherboard called UMX-TP-TX100R
and its version number is SCH_1.2.
4.4.

System commands

4.4.1. Query current control protocol

Description: Shows the RS-232 control protocol.
Command {P_?}
Response (CURRENT●PROTOCOL●
Legend:
Explanation: Protocol 1 is active here.
Info: User can query the protocol only. This command is reserved for compatibility reasons.
Page 16 / 43
Format
Build:<tag>)CrLf
<DATE> Month, Day and Year
<TIME> Hours, minutes and seconds
<tag> Identification number of the firmware
Format
(SL●END)CrLf
Slot 0 represents the motherboard.
<MB_DESC> The motherboard description contains the name and the
version number.
Format
=●#<x>)CrLf
<x> stands for the active protocol.
Example
→ {ct}
← (Compiled:Sep 21 2012 14:06:36
Build:4427)CrLf
Example
→ {is}
←
(SL# 0 UMX-TP-TX100R SCH_1.2)CrLf
←
(SL END)CrLf
→ {p_?}
← (CURRENT PROTOCOL = #1)CrLf
Section 4. Programmers reference
Example
