4.3.

Status and identification commands

4.3.1. View product type

Description: Identification of the device. Type 'i' or 'I' then the router responds its name.
Command {I}
Response (<PRODUCT_TYPE>)CrLf
Legend:
Explanation: The connected device is an UMX-TP-TX100R.

4.3.2. View serial number

Description: The extender responds its 8-digit serial number.
Command {S}
Response (<SERIAL_NUMBER>)CrLf
Legend:
Explanation: The connected device's serial number is 10170142.
Info: Only the last 4 numbers are written onto the back of the router

4.3.3. View Firmware version of the CPU

Description: View the CPU firmware revision.
Command {F}
Response (FW:<FW_VER><S>)CrLf
Legend: <FW_VERSION> is the firmware version. It is followed by <s> string which may
indicate special versions. <s>=r indicates standard version.
Explanation: The connected device's firmware version is 1.0.9r.

4.3.4. View installed controllers' firmware

Description: Shows the firmware revisions of the installed controllers.
Command {FC}
Response (CF●END)CrLf
Explanation: There is no installed controller. This command is reserved for compatibility
reasons.

4.3.5. View device's temperature

Description: Queries temperature status.
Command {ST}
Response (ST●<DESC>)CrLf
Legend:
Explanation: Internal temperature is shown.
Section 4. Programmers reference
Format
<PRODUCT_TYPE>
Format
< SERIAL_NUMBER > shows the serial number of the extender.
Format
Format
Format
N/A N/A N/A N/A N/A – reserved for compatibility reasons
<DESC>
INNER TEMPERATURE
Programmer's Reference Manual
→ {i}
← (I:UMX-TP-TX100R)CrLf
shows the router model.
→ {s}
← (SN:10170142)CrLf
→ {f}
← (FW:1.0.9r)CrLf
→ {fc}
← (CF END)CrLf
Example
→ {st}
← (ST CPU N/A N/A N/A N/A N/A 36.2C)CrLf
