Note:
Work the aileron up and down several
times to "work in" the hinges and
check for proper movement.

HINGING THE ELEVATORS.

Glue the elevator hinges in place using the
same techniques used to hinge the ailerons.

HINGING THE RUDDER.

Glue the rudder hinges in place using the
same techniques used to hinge the ailerons.
Hinge.
www.seagullmodels.com
WING TIP ASSEMBLY.
Covering.
Wing tip.
1) Attach the plastic wing tip to the wing. Use a
hobby knife to remove the covering at the wing
end.
2) Apply the epoxy to the surface of both wing
tip and wing end. The plastic wing tip is held in
position and install it to the wing end. Please
see pictures shown.
Fill epoxy.
Remove covering.
