CHEROKEE
8) Use plywood template to hold in place the
fuel tank with C/A glue to secure the fuel tank
inside the fuselage.
Plywood template.
C/A glue.
9) Use balsa stick to help prevent moveable
from transferring to the fuel tank.
Plywood template.
Balsa.
Fuel pick-up tube.
10
10) Connect the lines from the tank to the
engine and muffler. The vent line will connect
to the muffler and the line from the clunk to the
carburetor.
Fuel tank.
sure the fuel lines have not become kinked
inside the fuel tank compartment. Air
should flow through easily.

INSTALLING THE FUSELAGE SERVOS.

may need to adjust the size of the precut open-
ing in the mount. The notch in the sides of the
mount allow the servo lead to pass through.
collets onto the throttle servo. Test fit the servo
Fuel tank.
into the aileron servo mount.
vided with your radio system.
Throttle servo.
vent tube.
Fuel fill tube.
Instruction Manual.
Blow through one of the lines to en-
Because the size of servos differ, you
1) Install the rubber grommets and brass
2) Secure the servos with the screws pro-
Elevator servo.
Rudder servo.
