Elevator iberglass control horn.
INSTALL RUDDER CONTROL HORN.
Repeat steps to install the rudder control
horn as same as steps done for ailerons.
Fiberglass control horn
Rudder iberglass control horn.
Epoxy.
Epoxy.

INSTALLING THE FUSELAGE SERVOS.

Because the size of servos difer, you
may need to adjust the size of the precut
opening in the mount. he notch in the
sides of the mount allow the servo lead to
pass through.
1) Install the rubber grommets and brass
collets onto the throttle servo. Test it the
servo into the aileron servo mount.
2) Secure the servos with the screws pro-
vided with your radio system.
hrottle servo.
THROTTLE SERVO ARM
INSTALLATION.
Install adjustable servo connector in the
servo arm as same as picture below:
Loctite secure.
hrottle servo arm.
.
Elevator servo.
Rudder servo.
Adjustable servo
connector.
Servo arm.
7
