Fresh Water – The fresh water switch provides power to the fresh water pump. Depress the fresh water
switch to the forward position to activate the fresh water pump. The fresh water faucet/nozzle is installed
behind a white cap located just out side the transom door. Press the button on the handle to activate the
faucet/nozzle. If the fresh water system is not going to be in use, stow away the hose and move the
switch to the aft or down position to turn the pump off.
10
Baitwell Light - To activate the baitwell light, depress the switch to the up or forward position. This will
activate the LED (light emitting diode) light inside your baitwell tub. It is a soft white light that will keep
your bait moving and lively. It will also help you locate your bait on those early morning or late night
fishing trips. To turn the light off, simply depress the switch to the down or aft position.
11
Cockpit Lights (Optional) – Your vessel may be equipped with cockpit/courtesy lights. The lights have
LED (light emitting diode) bulbs with a lifespan of approximately 10,000 hours. To activate the lights,
depress the switch to the up or forward position. The lights give off a soft warm light which should not
affect your night vision, but will still provide you with enough light to safely move around your cockpit in
low visibility conditions.
12
Cabin Light – The cabin light switch provides power to the bullet lights located in the cabin. To activate
the lights, depress the switch to the up or forward position. Then press the on/off switch located on the
base of the light. The bullet lights can then be turned on individually.
13
Accessory - This 5 amp accessory switch can be used for additional dealer installed accessories. Please
check the amp rating of any new component and/or additional accessory before installation.
Battery Switch for Dual Batteries (Optional)
The battery switch is installed behind the hatch located just below the
transom door. The battery switch is for battery isolation, parallel operation
and disconnect.
The preferred switch position is port engine to position one (1) on the port
battery switch and starboard engine to position two (2) on the starboard
battery switch.
To test the operations of the battery switch, place the switch in the off position and try to start up the engine(s).
When the switch is off, you should not be able to start the engine(s).
If you have selected the twin-engine application, a dual battery switch for each engine is included as standard
equipment.
Caution: To avoid possible alternator/battery damage on twin-engine installations, make sure
that the dual battery switches are never left so both engines are connected together, (i.e., never
leave a switch on "BOTH" or "ALL"). Never switch battery positions while the engines are
running.
Lighting Systems
Baitwell Light
The baitwell light switch is located on the switch panel and is labeled baitwell with a light symbol on the switch.
To turn on the baitwell light, press the switch forward and open the baitwell lid to see if the baitwell light is on.
Press the baitwell light switch to the down or aft position to turn off the light.
Cabin Lights
The cabin light switch provides power to the three (3) bullet lights that are installed inside the cabin. To operate
the lights, depress the cabin light switch on the console to the forward or on position. Each light can then be
turned on or off individually by turning the base of the bullet light to the on or off position.
