Aileron Control Horn Installation - Seagull Models EDGE 540 Instruction Manual

Secure the servos with the screws pro-
vided with your radio system.
Wing panel
bottom.
Electric wire.
www.seagullmodels.com
Wing bottom.
String.
Aileron electric.
Plastic tape.
Repeat the procedure for orther wing
haft.

AILERON CONTROL HORN INSTALLATION

3x40mm.
1) Aileron control horn:
Mix a small amount of 30 minute epoxy and
lightly coat the inside of the hole in the aileron
and the control horn screw.
Wing.
Wing bottom.
drill hole
3.2mm.
2 sets.
Aileron.
15
