SPARROW HAWK
Type A.
Type A1.
Type A2.
Trim and cut.
Trim and cut.
Type A3.
12
Type B.
Trim and cut.
Trim and cut.
Type A or B.
Instruction Manual
2) While keeping the back edge of the
cowl flush with the marks, align the front of
the cowl with the crankshaft of the engine. The
front of the cowl should be positioned so the
crankshaft is in nearly the middle of the cowl
opening. Use the spinner backplate as a guide.
Hold the cowl firmly in place using pieces of
masking tape.
Type A4.
Machine screw 3 x 15 mm.
Type A5.
Type B1.
Type A or B.
