3-15 ENGINE
• While holding the generator rotor using the special tool,
remove the balancer shaft bolt
09930-44913: Rotor holder
• Remove the cam chain
• Remove the primary drive gear nut using the special
tool.
09930-44913: Rotor holder
A CAUTION
The primary drive gear nut has left-hand threads.
• Remove the spring washer
• Remove the primary drive gear
• Remove the keys
• Remove the cam chain sprocket
• Remove the circlip and washer
