5-1 CHASSIS

EXTERIOR PARTS

REMOVAL

FRONT SEAT
• Remove the seat with the ignition key.
RIGHT FRAME COVER
• Remove the screw.
• Remove the right frame cover.
LEFT FRAME COVER
• Remove the screw.
• Remove the left frame cover.
• Remove the seat lock.
REAR SEAT
• Remove the rear seat by removing the bolts.

REMOUNTING

Remount the seats, frame covers, front and rear fenders in
the reverse order of removal.
hooked part
hooked part
