2.1 Right Side Plate Asm (Fig. 2)
NO Index
1 2.1.01 881-A01-000A
2 2.1.02 00R-000-1101
3 2.1.03 00B-000-0905
4 2.1.04 881-A04-000A
5 2.1.05 00A-000-1211
6 2.1.06 00M-000-0403
7 2.1.07 881-708-0000
8 2.1.08 881-707-0000
9 2.1.09 00B-L12-60ZZ
10 2.1.10 08P-17G-0635
11 2.1.11 00B-MXL-088C Belt, 0.2P, 88XL
12 2.1.12 881-A12-000A
13 2.1.13 881-A13-000A
14 2.1.14 00G-M10-1912 Gear, M1.0, 19T, OD 12, Idler
15 2.1.15 00B-L12-80ZZ
16 2.1.16 881-118-000A
Fig. 2
P/N
Side Plate,
Rubber Foot
Angle Bracket
Stopper
Asm, PCB, Power
Motor, SQ, 2.58V, 3A
Crank, Knife Driving
Bushing, OD8, ID6.2
Ball Bearing, L-1260ZZ
Pulley, 0.8 P, 17G, ID6.35
Standoff, Slitter Positioning
Stud, Idle Gear
Ball Bearing, L1280ZZ
Case, R, CC-228
Name
Right
- 8 -
Q'TY
1
2 NBR
4
1
PCBA
1
1
1
1
1
1
MAR
1
1
1
1
2
1
