Left Side Plate Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.2 Left Side Plate Asm (Fig. 3)
NO Index
1 2.2.01 881-B01-000A
2 2.2.02 00R-000-1101
3 2.2.03 00B-000-0905
4 2.2.04 881-B04-000A
5 2.2.05 00A-000-1121
6 2.2.06 00A-000-1601
7 2.2.07 00A-000-1001
8 2.2.08 00M-000-0401
9 2.2.09 02P-17G-0500
10 2.2.10 00B-0XL-132C
11 2.2.11 881-B11-000A
2.2.12 00A-000-1501
12
881-102-0002
13 2.2.13 00D-000-0303
2.2.14 00A-000-0188
14
00B-000-0943
00S-000-6105
15 2.2.15 00C-000-2050
16 2.2.16 00S-000-1513
17 2.2.17 881-117-000A
Fig. 3
P/N
Side Plate,
Rubber Foot
Angle Bracket
Stopper
Asm, PCB, Interface
Asm, PCB, LCD Interface
Asm, PCB, LOGIC
Motor, CKM245-01AH
Pulley, 0.2 P, 17G, ID5.00
Belt, 0.2P, 132XL
Standoff, Slitter Module Positioning
Asm, PCB, Control Panel
Key Pad, CC-228
Display, LCD
Asm, Interlock Switch
Bracket, Interlock Switch Mounting
Switch, Interlock
Cover, Interlock Switch
Sensor, Interrupter, EE-SV3
Case, L, CC-228
Name
Left
- 9 -
Q'TY
1
2 NBR
4
1
PCBA
1
1 PCBA
1 PCBA
1
1
MAR
1
1
PCBA
1
PC
1
1 PC/PCBA
3
3
3
3
1
1
