Front Lower Transport Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.8 Front Lower Trasport Roller Asm (Fig. 7)
NO Index
1 881-H01-000A
2.8.01
2 2.8.02 00G-M10-1910 Gear, M1, 19T, ID10
3 2.8.03 00B-F19-80ZZ
4 2.8.04 00C-016-080A
5 08P-51G-0800
2.8.05
Fig. 7
P/N
Roller, Transport, CC-228
Ball Bearing, LF-1980ZZ
Collar, OD16, ID8
Pulley, 0.8 P,51G,ID8
Name
- 14 -
Q'TY
1
1
2
1
2
