Front Upper Transport Roller Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.10 Front UpperTransort Roller Asm (Fig. 9)
NO Index
1 881-L01-000A
2.10.01
2 2.10.02 00G-M10-1910 Gear, M1.0, 19T, ID10
3 2.10.03 881-L03-000A
4 2.10.04 00H-L12-800A
5 00B-F12-80ZZ
2.10.05
6 2.10.06 00B-L12-80ZZ
Fig. 9
P/N
Roller, Upper, Transport, CC-228
Nylon Graphite Gasket, OD14, ID8.2
Housing, 1280 Ball Bearing (00H-000-0501)
Ball Bearing, F-1280ZZ
Ball Bearing, L-1280ZZ
Name
- 16 -
Q'TY
1
1
1 Nylon
2
2
2
