2.9 Rear Lower Transport Roller Asm (Fig. 8)
NO Index
1 881-H01-000A
2.9.01
2 2.9.02 00G-M10-1910 Gear, M1.0, 19T, ID10
3 2.9.03 00B-F19-80ZZ
4 2.9.04 00C-016-080A
5 08P-51G-0800
2.9.05
6 2.9.06 00B-MXL-082C
Fig. 8
P/N
Roller, Transport, CC-228
Ball Bearing, F-1980ZZ
Collar, OD16, ID8
Pulley, 0.8 P,51G,ID8
Belt, 0.2P, 82MXL, 8mm
Name
- 15 -
Q'TY
1
1
2
1
2
MAR
1
