Cutter Transmission Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.13 Cutter Transmisaion Asm (Fig. 12)
NO Index
1 881-704-000A
2.13.01
2 881-P02-000A
2.13.02
3 2.13.03 881-719-000A
4 2.13.04 881-707-000A
5 881-P05-000A
2.13.05
6 2.13.06 00B-F19-10ZZ
7 2.13.07 881-721-000A
8 2.13.08 881-720-000A
9 2.13.09 881-722-000A
Fig. 12
P/N
Knife, Upper. CC-228
Plate, Upper K
Link
Bushing, OD8, ID6
Shaft, Knife Driving
Ball Bearing, F-1910ZZ
Arm, R, Knife Driving
Arm, L, Knife Driving
Shutter, Index, CC-228
Name
M
NIFE OUNTING
- 19 -
Q'TY
1
2
2
2
1
2
1
1
1
