Rear Upper Transport Roller Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.11 Rear UpperTransnsport Roller Asm (Fig. 10)
NO Index
1 881-M01-000A Roller, Transport
2.11.01
2 2.11.02 00G-M10-1910 Gear, M1.0, 19T, ID10
3 2.11.03 881-L03-000A
4 2.11.04 00H-L12-80ZZ
5 00B-F12-80ZZ
2.11.05
6 2.11.06 00B-L12-80ZZ
Fig. 10
P/N
Nylon Graphite Gasket, OD14, ID8.2
Housing, 1280 Ball Bearing, Transport Rocker
Ball Bearing, F-1280ZZ
Ball Bearing, L-1280ZZ
Name
- 17 -
Q'TY
1
1
1 Nylon
2
2
2
