Cutting Knife Asm - Duplo DocuCutter CC-228 Service And Parts Manual

2.14 Cutting Knife Asm (Fig. 13)
N
Index
O
1 881-711-000A
2.14.01
2 881-705-000A
2.14.02
3 2.14.03 881-714-000A
2.14.03.1 881-714-010A
2.14.03.2 881-714-020A
2.14.03.3 881-714-030A
2.14.03.4 00B-0L9-40ZZ
4 2.14.04 881-717-000A
5 2.14.05 881-716-000A
2.14.05.01 881-716-010A
2.14.05.02 881-716-020A
2.14.05.03 881-717-030A
2.14.05.04 00B-0L9-40ZZ
2.14.06 881-715-000A
2.14.06.01 881-715-010A
2.14.06.02 881-716-020A
2.14.06.03 881-716-030A
2.14.06.04 00B-0L9-40ZZ
6 2.14.07 881-718-000A
7 2.14.08 00S-000-1515
P/N
Chassis, Cutting Knife Mounting
Knife, Lower, CC-228
Asm, Middle, Upper Knife Holding Spring
Spring, Middle, Upper Knife Holding Spring Asm
Pin, Middle, Upper Knife Holding Spring Asm
Bushing, Middle, Upper Knife Holding Spring Asm
Ball Bearing, L940ZZ
Nut, Middle, Upper Knife Holding Spring Asm
Asm, Right, Upper Knife Holding Spring
Spring, Right, Upper Knife Holding Spring Asm
Pin, R/L, Upper Knife Holding Spring Asm
Bushing, R/L, Upper Knife Holding Spring Asm
Ball Bearing, L940ZZ
Asm, Left, Upper Knife Holding Spring
Spring, Left, Upper Knife Holding Spring Asm
Pin, R/L, Upper Knife Holding Spring Asm
Bushing, R/L, Upper Knife Holding Spring Asm
Ball Bearing, L940ZZ
Nut, L/R Upper Knife Holding Spring Asm
Sensor, Mark Reader, White, EE-SB5
Name
- 20 -
Q'TY
1
1
1
1
1
1
2
1
1
1
1
1
2
1
1
1
1
2
2
1
