2.16
Slitter Mounting Chassis
NO
Index
1
881-S01-000A
2.16.01
2
2.16.02
881-S02-000A
3
2.16.03
00M-000-0002
4
2.16.04
881-111-000A
881-111-010A
Fig. 15
Asm (Fig. 15)
P/N
Chassis,
Slitting Module Mounting
Stud,
Rear Safety Cover
Magnet, Rear Cover Position
Thumb Screw, Slitting Module Fastening
Spring, Compression, Slitting Module Fastening
Name
- 24 -
Q'TY
1
2
2
1
1
