Calibrations
The calibration allows calibrate cutting mark, cutting length, offset and top margin by:
◎Select Job #4
◎Holding
◎Tip on
◎Tip on
1. Length
◎ On Job #4, set it to without cutting mark mode, feed a piece of paper to cut the top margin, make
sure the cut top margin is 12.7mm, if not calibrate the top margin first then do Length calibration.
◎Select length:50. Feed a Letter Size sheet thru, the sheet will be cut into half which is 5.5", compare
the 2 X 5.5", if the 1
nd
and 2 half are exactly the same; If the first cut is greater than the 2
decrease the setting until the 2 half is equal. Each press on
increment or decrement
for 5 seconds. mark:50 length:50 offset:50 margin:50 is displayed.
to select the item you are going to calibrate.
to save when the calibration is done.
st
half cut is shorter than the 2
nd
half, tip on
- 27 -
to adjust until the 1
nd
half, tip on
or represents 0.1mm
st
half
to
