[OFF Event Operation]
If [Enable] is set, [Preset], [Video Record] and [E-mail Notification] will be executed according to their settings when
a linked event (OFF event) is completed.
[Ongoing ON Event Operation]
Select the operation to be performed when an ON event is triggered.
If [Enable] is selected, [Video Record] and [E-mail Notification] will be executed according to their settings during the
linked event.
R11
[Preset]
If you specify a preset, the camera angle will automatically move to the preset location when a linked event is
triggered.
It is necessary to set presets beforehand with [Control for Admin] > [Preset/Initial Setting] > [Preset Setting] (P. 170).
Note
This cannot be set when [Event Type] is set to [Intelligent Function].
[Video Record]
Select whether to record video depending on the linked event.
If you select [Enable] and a linked event is triggered, video will be transmitted to the recording destination specified
in [Video Record Action] (P. 96).
[E-mail Notification]
Select whether to send an e-mail notification depending on the linked event.
If you select [Enable] and a linked event is triggered, an e-mail notification will be sent.
To use e-mail notification, you must set [Video Record] > [E-mail Notification] (P. 102) beforehand.
[External Device Output for ON Event]
Select whether external device output (1 or 2) is active or inactive when an ON event is triggered.
[External Device Output for OFF Event]
Select whether external device output (1 or 2) is active or inactive when an OFF event is triggered.
[Audio Playback at ON Event]
If you select [Enable], the sound clip specified in [Sound Clip] will play back when a linked event is triggered.
Note
This can only be set when [Event Type] is set to [External Device Input] or [Intelligent Function].
[Audio Playback at OFF Event]
If you select [Enable], the sound clip specified in [Sound Clip] will play back when a linked event completes.
[Sound Clip]
Select the sound clip when [Audio Playback at ON Event] or [Audio Playback at OFF Event] has been set to [Enable].
You must register the sound clip with [Video and Audio] > [Audio Settings] (P. 88) beforehand.
[Volume]
Enter the volume for the sound clip.

Linked Event Operation Examples

This shows linked event status examples according to the ON/OFF combinations for Event 1 and Event 2.
In the examples below, [Event Gap] is 4 seconds and each cell in the graph below represents 1 second.

[Event Linking Method] Set to [OR]
Only One Event ON
Event 1
Event 2
Consolidated
state
ON
OFF
ON
OFF
ON
OFF
4
