devices on ceilings or high up on walls. You can also power these APs with optional, certified, external
power supplies.
Table 6: Universal Specifications for an External Power Supply
Item
Enclosure material
AC Input
DC output
Output current (max)
Output power (max)
Power supply Part Number 30512 (WS-PSI12V-MR2), which includes six regional adapters, is
recommended for use with all AP3935 APs.

Internal Antenna APs

Internal Antenna Access Points
The AP3935i is an indoor access with eight integrated internal antennas. The following specifications are
for the internal antennas:
Table 7: AP3935i Internal Antennas
Model Type Application
AP3935i Indoor
The following radiation patterns apply to the antennas in the AP3935i only. In these diagrams, 0 degree
is the AP's front and +/- 180 degree is the AP's back.
The diagrams show radiation patterns along one horizontal plane (XZ) and two vertical planes (XY and
YZ). The X, Y, and Z axes are defined as follows.
ExtremeWireless™ AP3935i & AP3935e Installation Guide
Specification
Plastic housing
100-240V
12V
2A
24W
Description Gain (dBi)
MIMO, Single- 3dBi
band
5dBi
Specifications
Frequency (GHz) Connector
2.4 None
5 None
