Security Violations
Isolate from network
Isolate from Closed IP
Generate system event
Overview (Red Button)
Discover (Green Button)
Unalloc (Yellow Button)
Advanced (Blue Button)
Refresh (Purple)
60
On detection of a security breach this option will prevent any device
connected to the breached port from accessing the general corporate
network (if available). Video will continue to be streamed on the Closed
IP side of the network.Reconnect after
network will be attempted after a security breach once this period has
elapsed. If the security breach is detected again, connection to the
public network will remain blocked.
If a security breach is detected, the video source is isolated from the
Closed IPTV network.
Select this option to report port violation as system events which can be
used as a input to an alarm zone (e-mail, alarm etc ) on the NVR.
Select to open the Camera -> Overview page.
Select to open the Closed IPTV -> Discover page which can be used to
force discovery of all Layer 3 Enhanced CCTV Switches connected to
the NVR.
Select to open the Camera->Unallocated Cams page.
Select to open the Closed IPTV->Advanced Page,
Refreshes the information on the current page.
SD Excel
Reconnection to the
refer to 'Advanced'.
