Dedicated Micros SD Excel Installation Manual page 131

Alarm Server ref. ID
Remote Alarm Reporting
Remote Cam Fail Reporting
Remote Startup Reporting
ARC Ping Enabled
Alarm Responder Port
Dial Retry Time (secs)
Dial Count
Zone Act (Green)
Network (Yellow)
Email (Blue)
Refresh (Purple)
This is the reference name/ID that will be presented to the RVRC
viewing application. It should therefore have some significance to the
Operator.
This must be enabled for the unit to automatically connect on alarm.
Enabling this option ensures the unit reports camera failure on any of
the inputs to the RVRC.
This will send an alarm report when the unit starts up. Any system
resets will be identified.
Should the modem/router at the Alarm Receiving Centre be dormant, the
unit will 'Ping' the ARC prior to sending reporting data.
This specifies the network port number used for reporting to the alarm
server. In normal circumstances this should be left at the default value
(23).
If the initial connection attempt fails, the unit will wait for the specified
time period (in seconds) before attempting to re-connect.
This identifies the number of times the unit will attempt to connect after
a failed attempt. A setting of '0' means no limit and the unit will continue
to try and connect until successful.
Select to open the Alarm->Zone Actions menu
Select to open the Network->Network menu
Select to open the Network->E-mail menu
Refreshes the information on the current page
131
