Alarm Duration sec
Zone Input Rule
Input
Zone OR Input
Zone AND Input
Zone NOT Input
Alarm 24Hr
Entry Route Zone
Exit route Zone
Exit Terminator
Entry Initiator
Enable in Unset
Enable in Set
Enable in Override
Activity (Green)
Zone Act (Yellow)
Alarm in (Blue)
Refresh (Purple)
106
This is the minimum time period in seconds (from the start of the alarm)
that is protected from being overwritten. This time will include the alarm
trigger, the pulse extension and any post alarm recording. It will not
include pre-alarm images.
This determines which input(s) will trigger the zone alarm:
This sets an input or system function as the primary alarm trigger.
Select from Alarms 1-32, Video Alarm 1-16, Preset 1-16, Disk Low, Disk
Full, Panic, Archiving Slow, Archiving Fault, Virtual 1-16, and Keyword
Channel 1-32 (which will trigger the Alarm if any or the 32 programmed
keywords are detected on the selected channel).
The Zone OR Input identifies an alternative input that can also be used to
trigger the zone alarm. This means an alarm trigger can be received on
the Zone Alarm Input or the Zone OR Input for the zone to be activated.
The Zone AND Input identifies that an alarm trigger needs to be
received on both the Zone Alarm Input and the Zone AND Input for
the zone to be activated and the alarm action to the
automatically initiated.
The unit will only issue the alarm actions if the trigger is received on the
zone alarm input and NOT on the Zone input.
This option can be enabled for alarms that do not require change at
any time and are to remain as programmed i.e. Panic Alarm. When this is
selected, the Set, Unset and Override options are disabled.
This creates deferred alarms along a specified route while the
entry time is active. This is in compliance with BS8418 (the British
Standard for remote video reporting centres). Diverting from the entry
route during the countdown will result in the alarm being triggered
immediately. This allows staff entry without triggering an alarm prior to
switching the system to Set mode.
This creates deferred alarms along a specified route while the exit time
is active. This is in compliance with BS8418 (the British Standard for
remote video reporting centres). Diverting from the exit route during the
countdown will result in the alarm being triggered immediately. This allows
staff to exit without triggering an alarm.
This will trigger the exit timer if the system is set. A countdown timer will
automatically start when the alarm is activated and ensure the alarm
system is not activated by other specified alarm triggers for the Set time
i.e. allowing a Guard to exit a building.
This will trigger the entry timer if the system is set. A countdown timer
will automatically start when the 'primary' alarm trigger i.e. front door,
is actioned. This ensures the alarm system is not activated by other
specified alarm triggers for the set time
Each alarm can be configured to be active when the unit is in a specific
operation mode. Enable this for the zone alarm to be active in Unset
operation mode.
Each alarm can be configured to be active when the unit is in a specific
operation mode. Enable this for the zone alarm to be active in Set
operation mode.
Each alarm can be configured to be active when the unit is in a specific
operation mode. Enable this for the zone alarm to be active in Override
operation mode.
Select to open the Alarm->Activity menu
Select to open the Alarm->Zone Actions menu
Select to open the Alarm->Inputs menu
Refreshes the information on the current page
