Dedicated Micros SD Excel Installation Manual page 108

Add Still Image
Email Image
Protect alarm Images
Switch Spot Monitor
Goto Preset
Email Reporting
VMD/Activity Inhibit
Enable Buzzer
Relay
Relay Duration
Alarm Image Snapshot Delay
Play Audio Message
IMPORTANT:
Switch Main Monitor
Preset Camera
Preset
Cam Options (Yellow)
Rem Report (Red)
Email (Green)
Cam Options (Yellow)
Relays (Blue)
Refresh (Purple)
108
This will record a still image of the trigger along with the standard
recording. This can then be sent on to an external destination.
If this option is selected, a JPEG will be added to the reporting email (if
Email Reporting is selected).
Alarm images can automatically be protected from being overwritten.
Select to display the alarm zone Primary camera on the Spot Monitor.
It is possible to action a camera to automatically be sent to a preset
position when an alarm is triggered.
The unit can send an email when an alarm is detected. Refer to
'Network->Email' for further information.
Select to inhibit (ignore) the VMD/Activity detection feature. Refer to
'Alarm Settings->Activity Setup' for further information.
Select to activate the unit's internal buzzer upon alarm receipt.
Select an onboard or external relay to automatically close on receipt of
an alarm.
Enter (in seconds) how long the relay is to remain closed.
This figure allows a delay to be introduced before an alarm snapshot is
taken. This is used when the alarm relates to a PTZ camera which has
to travel to a preset position.
Following a Zone alarm trigger, a specific audio message
can be played.
Audio messages must be uploaded to the unit in mono 8k wav format only.
The following naming convention must be used: messageXX.wav
i.e. message00.wav, message01.wav etc.
An FTP client should be used to place the wav files in the following folder:
\mdd0\messages folder .
Select to display the alarm zone Primary camera on the
Main Monitor.
Activate a telemetry camera to move to a preset position on receipt of
the alarm.
Select the preset the activated telemetry camera (above) will move to.
Select to open the Zone Action Camera Configuration menu.
Select to open the Network->Remote Reporting menu
Select to open the Network->Email menu
Select to open the Alarm->Zone Actions->Zone Action Configuration
menu
Select to open the Alarm->Global Actions menu
Refreshes the information on the current page
SD Excel
