Oracle Dome Configuration

If a camera channel has a Dedicated Micros Oracle dome camera connected, the Oracle Configuration
menus can be used to view settings and establish Presets, Patrols and Privacy Masks.
IMPORTANT:
The Status page details fundamental information regarding the status of the Oracle Dome i.e. the model
type and the version of software/firmware installed.
The Presets page allows Preset positions to be configured and stored.
The Sectors page enables the cameras 360 degree field of view to be effectively split into 32 segments.
These segments can be named and displayed via the On Screen Display (OSD Excel).
The Patrols page allows camera patrol sequences to be established and configured. The Patrol feature
uses established preset positions to automatically pan, tilt and zoom the camera in the selected
sequence.
The Privacy Masks page allows privacy masking to be established and configured. The Privacy Mask
feature can be used to 'blank out' sensitive or private areas which appear in the camera
field of view.
The OSD Excel Settings page allows the Oracle Dome OSD Excel (On Screen Display) information to be
configured. This text will accompany displayed camera images in the Viewer menus.
The Camera Settings page enables features such as white balance and shutter speed to be configured.
The Event Settings page allows actions to be established and configured for the Oracle Dome camera
following an alarm. A Home position can be established and the delay time set for what period of inactivity
is required before the camera will be sent to its home position.
160
The 'Restrict public access (Eth B)' setting (Closed IPTV-> Settings) must be enabled if
using Oracle IP domes in the Closed IPTV environment.
