Network Settings

The Network Settings menus allow configuration of the unit's network functionality. Key network settings
can be established such as 'fixing' the unit's IP address and maximum transmission rate. Email, remote
reporting on alarm and FTP download can also be configured. Refer to the individual menus for further
details.
The Network Settings page allows configuration of the unit's network connections such as the name
assigned to the unit and its IP address.
The Live Transmission page enables JPEG and MPEG profiles to be created for transmitting images via
a High, Medium or Low quality network connections to any viewing software or to another unit using this
one as an IP source.
The Multicast page allows recordings from the unit's camera inputs to be forwarded to a port address;
enabling multiple viewers to view live data using a suitable media player without the need to directly
connect to the unit.
The Email page allows configuration of the Email feature. The unit can automatically transmit an email to
an SMTP Server following an event i.e. on receipt of an alarm or a camera failure notice.
The Remote Reporting page allows a Remote Video Receiving Centre's (RVRC) configuration details to
be entered. The RVRC will then be contacted following a selected event occurring i.e. reported alarm or
camera failure.
The Web Cam page allows recordings from any of the unit's camera inputs to be forwarded to a
Webserver. The images can then be incorporated into a web page and accessed via a standard
web browser.
The FTP Download page allows data to be archived to a central FTP server. This could be on receipt of
an alarm, Activity activation or at a scheduled time to back-up recorded video.
The Firewall page allows the user to block access to the unit via specific network port(s).
