Appendix E - Locate IP Address (Serial)

Locating the unit IP address using the serial port

For guidance on locating the unit's IP address via a serial port connection, please see below:
1. With the mains power off, connect a standard 9DF-9DF RS232 communications cable from
the PC to one of the serial port connections on the rear of the unit.
2. On the PC, click Start->Programs->Accessories->Communications->Hyperterminal and
create a new connection via the COM port using these settings.
3. Power the unit, the Power LED on the unit will illuminate.
4. Hyperterminal will display the communications information as the unit boots up. This will
include the IP address, Subnet and Gateway.
212
Bits per second
Data Bits
Parity
Stop bits
Flow Control
115200
8
None
1
None
SD Excel
