Dedicated Micros SD Excel Installation Manual page 196

Archive Media
Include Viewer Application
Used (Blue)
Required (Green)
Free (White)
Status
Progress
Red
Green
Yellow
Purple
Note: You can navigate away from the Copy menu and the archive procedure will continue
To Copy Events/Images to a USB Device
1.
2.
3.
4.
5.
To Copy Events/Images to a CD-R/DVD-R
1.
2.
3.
4.
5.
196
Select the media device (USB or CD-R/DVD-R) for archive purposes.
Select whether the application required to view archived data is
included in the download.
Displays the space (as a percentage) already used on the chosen
media device.
Displays the space (as a percentage) required to download the
selected archive(s).
Displays the space (as a percentage) that will remain following
the download.
Displays messages relevant to the archive process i.e. 'Archive
In Progress'.
Displays the progress of the current archive (as a percentage
of completion).
Copy
Delete
Clear All
Exit
Insert a USB Device into the USB port on the front of the unit.
Select USB from the Archive Media checkbox.
Select the Copy option (Red) to start archive.
Selected items are then saved to the USB device.
The USB export progress is displayed as a %. On completion the status will read 'Archive
Complete'.
Insert a -RW CD-R/DVD-Rinto the CD/DVD drive on the front of the unit.
Select CD/DVD from the Archive Media checkbox.
Select the Copy option (Red) to start archive.
Selected items are then saved to the CD-R/DVD-R.
The CD/DVD export status is displayed as a %. On completion the status will read 'Archive
Complete'.
Select to begin the download process.
Select to delete the highlighted archive only.
Select to delete ALL archives currently displayed in the
Copy menu.
Select to exit the Copy menu.
