I - 2. Connections

BEFORE CONNECTING THE ROUTER PLEASE READ THE
Workplace Conditions. Main Characteristics
•
Areas with excessive humidity and dust should be avoided.
•
Direct exposure to sunlight should be avoided as well as other heat sources.
The device should not be placed amongst books, papers, magazines or other
element that could hinder natural air circulation.
•
The device should not be placed very close to strong electromagnetic fields
such as speakers, engines, etc.
•
Knocks and/or strong vibrations should be avoided during transport, operation
and storage.
WARNING: Electric supply current, telephone and communication cables are
dangerous. To prevent electric shock while installing, moving or opening the
device covers, cables should be disconnected and connected as follows:
To Connect
Ensure that the on/off power supply switch is in
the OFF position
Check that the power supply is not connected to
either the main electricity supply or the device
Connect all data cables
Connect the power supply to the device
Connect the power supply to the main electricity
supply
Place the device's on/off power supply switch in
the ON position

I - 2.1. Power Source Connection

The ATLAS 150
To avoid electric shocks, residual current circulation and other unwanted effects,
also affecting communications, the following is recommended:
FOLLOWING INSTRUCTIONS CAREFULLY
router is powered with an external AC/DC source.
ATLAS 150
Installation
To Disconnect
Place the on/off power supply switch in the
OFF position
Disconnect the power supply from the main
electricity supply
Disconnect the power supply from the device
Disconnect the data cables
