CyberData 011097 Operation Manual page 23

Existing Loudspeaker
(High power mode with Injector)
Operations Guide
Figure 2-13. Line Out Connection
Generic Ethernet Switch
1 2
Line-out
Connection
Existing Amplifier
Loudspeaker Amplifier
Figure 2-14. Speaker Out Connection
802.3af Compliant Ethernet Switch
High Power PoE Switch
1 2
PoE Injector
011068 Loudspeaker
Loudspeaker Amplifier
(up to 25 watts)
3 4 5 6
IP Phone
(up to 25 watts)
3 4 5 6
VoIP Phone
930362L
Installing the VoIP V2 Loudspeaker Amplifier
Loudspeaker Amplifier Setup
IP PBX Server
IP PBX Server
CyberData Corporation
15
