CyberData 10860 Installation Quick Reference Manual

Mounting the Enclosure
Contacting CyberData
Corporate Headquarters
CyberData Corporation
2555 Garden Road
Monterey, CA 93940, USA
Phone: 831-373-2601
Fax: 831-373-4193
www.CyberData.net
Sales: (831) 373-2601 ext. 334
Support: 831-373-2601 ext. 333
Web: http://www.cyberdata.net/support/contactsupportvoip.html
RMA Dept: (831) 373-2601 ext. 136
Email: RMA@CyberData.net
RMA Status: http://www.cyberdata.net/support/rmastatus.html
Warranty information is available at:
Web: http://www.cyberdata.net/support/warranty/index.html
© 2009, CyberData Corporation, ALL RIGHTS RESERVED
To mount the enclosure:
1. Prepare holes for the screws.
2. Plug in the power adapter and use the
blue power light to verify that the power
is on.
3. Plug the Ethernet cable into the
loudspeaker amplifier. The yellow light
verifies the network connection.
4. For wall mounting, use the three
#8 SHEET METAL SCREWS to
secure the speaker.
Warranty
CyberData warrants its product against defects in material or workmanship for
a period of two years from the date of purchase. Should the product fail within
the warranty period, CyberData will repair or replace the product free of
charge. This warranty includes all parts and labor.
Should the product fail out-of-warranty, a flat rate repair charge of one half of
the purchase price of the product will be assessed. Repairs that are in
warranty but are damaged by improper modifications or abuse, will be
charged at the out-of-warranty rate. Products shipped to CyberData, both in
and out-of-warranty, are shipped at the expense of the customer. Shipping
charges for repaired products shipped back to the customer by CyberData,
will be paid by CyberData.
CyberData shall not under any circumstances be liable to any person for any
special, incidental, indirect or consequential damages, including without
limitation, damages resulting from use or malfunction of the products, loss of
profits or revenues or costs of replacement goods, even if CyberData is
informed in advance of the possibility of such damages.
For product service, contact the Returned Materials Authorization (RMA)
department. A product will not be accepted for return without an approved
RMA number. Send the product, in its original package, to: CyberData Corpo-
ration, 2555 Garden Road, Monterey, CA 93940, Attention: RMA "your RMA
number"
The most recent warranty information is available at:
Web: http://www.cyberdata.net/support/warranty/index.html
930115H Quick Reference
Installation Quick Reference
VoIP Loudspeaker Amplifier
(Wireless, AC powered)
SiP Compliant
010860
The Loudspeaker Amplifier (Wireless, AC powered) is a Voice-over-IP public address speaker that uses a single cable to
connect to existing LANs.
Parameter
IP Addressing
IP Address
Web Access Username
Web Access Password
Subnet Mask
Default Gateway
Typical Loudspeaker Amplifier System Installation
802.3af Compliant Ethernet Switch
1
Access Point
VoIP Loudspeaker Amplifiers
Getting Started
Download the VoIP Loudspeaker Amplifier (Wireless, AC powered) Operations Guide PDF file at the VoIP Loudspeaker
●
Amplifier product page at:
http://www.cyberdata.net/support/voip/index.html
Follow all instructions in the guide.
●
Create a plan for the locations of your loudspeaker amplifiers.
●
● Prior to installation, consult local building and electrical code requirements.
Loudspeaker Amplifier Parts
(1) Enclosure Assembly (1) Wall Mounting Kit
(3) Plastic Ribbed Anchors
Quick Reference
Factory Default Setting
static
192.168.3.10
admin
admin
255.255.255.0
192.168.3.1
2 3 4 5 6
VoIP Phone SIP Server
(3) #8 Sheet Metal Screws
930115H © 2009, CyberData Corporation, ALL RIGHTS RESERVED
