HARDWARE AND INSTALLATION
CAUTION: Use only the power supply provided with the FaxFinder. Using any other power supply voids the
warranty and can damage the FaxFinder.
3. Verify power.
■
■
4. Connect FaxFinder to Ethernet Network. Plug one end of your RJ-45 Ethernet cable into the FaxFinder's
Ethernet port (labeled LAN1) and the other end into your network Ethernet hub. This Ethernet cable is
not included with your FaxFinder unit.
Warning:
Before connecting to the Ethernet Network, determine if the network is a 192.168.2.x subnet. FaxFinder's
factory default IP address is 192.168.2.1. Connecting the FaxFinder to a network that has a different device
at the same IP address will cause data interference.
If your existing Ethernet network uses a 192.168.2.x subnet, connect from the Administrative PC to the
FaxFinder using an RJ-45 Ethernet cable and configure the FaxFinder's IP address to an IP address currently
available on the Ethernet network. (Refer to Configuring FaxFinder's IP address and Network
Settings.)When the FaxFinder's IP address has been configured, you can connect the FaxFinder into the
network.
16
The Power LED comes on immediately after power is applied.
FaxFinder takes a short time to boot up when you apply power.
®
