built into the printer; see table below. As an example, to encode FNC2 into a Code128
Subset A bar code, send the ASCII & (DEC 38, HEX 26) followed by an ASCII B (DEC 66,
HEX 41). Code FNC2 will be encoded.
ASCII
96
97
98
99
100
101
102
Control Codes: Control character encoding into Code 128 Subset A by sending these
control codes:
The following example prints a Code128 Auto bar code:
<STX>L
D11<CR>
1W1J000000025002512345&G10Z2133021AK<CR>
121100000000100Barcode W1J<CR>
E
When scanned this bar code will decode as follows:
[C]1234[B]5[F1]10Z2 [C]133021[B]AK(95)
Class Series 2 Programmer's Manual
Appendix G – Bar Code Details
2 CHAR
&A
&B
&C
&D
&E
&F
&G
Table G-6: Special Character Handling
` = NUL
a through z = 1 - 26
{ = ESC
| = FS
} = GS
~ = RS
ASCII 127 = US
CODE A CODE B
FNC3 FNC3
FNC2 FNC2
SHIFT SHIFT
CODEC -NA-
CODEB FNC4
FNC4 CODEA
FNC1 FNC1
Barcode W1J
CODE C
-NA-
-NA-
-NA-
-NA-
-NA-
CODEA
FNC1
233
