Appendix C

Available Fonts – Sizes, References, and Samples
All character bitmapped fonts available on the printers are described in this section. Each
font has a name (Font ID) associated with it for use in programming. Use the Font Number
(in the left column of Table C-1) in field b of the Format Record header to cause the printer
to use the corresponding font.
Fonts 0 through 8 use the slash zero (Ø) conventions for distinguishing between the zero
and the alphabetic O. The slash can be removed with the label formatting command z.
These fonts are non-proportional (monospaced). Therefore, all of the characters take up the
same amount of space when printed. This is helpful when using variable data in a fixed
area. The sizes of these fonts are shown on the following pages.
The CG Triumvirate font number 9 is a proportional font. Each character will take up a
different amount of space when printed. For example, the letter W will be wider than the
letter I.
Font
Number
0 32-127, 255
1 32-168, 171, 172, 225, 255
2 32-168, 171, 172, 225, 255
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153, 154, 156, 157,
3
165, 168, 225, 255
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153, 154, 156, 157,
4
165, 168, 225, 255
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153, 154, 156, 157,
5
165, 168, 225, 255
32, 35-38, 40-58, 65-90, 128, 142-144, 146, 153, 154, 156, 157,
6
165, 168, 225, 255
7 32-126
8 32, 48-57, 60, 62, 67, 69, 78, 83, 84, 88, 90
9 Dependent upon selected symbol set; see Appendix H.
Table C-1: Valid Human-Readable Font (Internal) ASCII Characters
Class Series 2 Programmer's Manual
Valid ASCII Characters (decimal)
Use with Record
Structure Type
Internal
Bitmapped
Fonts
Scalable Font
177
