Datamax E-Class Mark II Programmer's Manual page 234

<STX>L
D11<CR>
1W1d4400000100010This is the data portion<CR><CR>
121100000000100Barcode W1D<CR>
E
Manual Formatting (W1D)
With bar code identifier "D", minor changes allow flexibility for data entry. (Spaces
have been added for readability.)
[q,] [e [m] i,]
Where:
Field Valid Inputs
q
e
m
I
immediately followed
cdata
<CR>, <CR><CR>
term
[1]
When Data Input Mode = Automatic, Kanji data cannot be used; Manual data input required.
[2]
When using manual formatting, commas are required between format fields and data types.
[3]
<CR> represents the line termination character as defined by the current control code set or
after use of Txx, line field terminator label format command.
222
Appendix G – Bar Code Details
cdata cdata cdata...cdata term
1, 2 QR Code Model number, optional. Model 2 is the default.
Error Correction Level (Reed-Solomon) – Four levels
allowing recovery of the symbol code words:
H = Ultra Reliability Level (30%)
H, Q, M, L
Q = High Reliability Level (25%)
M = Standard Reliability Level (15%)
L = High Density Level (7%)
Mask Number, optional:
None = Automatic Selection
0 – 8, none
0-7
8
Data Input Mode:
A = Automatic setting, ASCII
A, a, M, m a = Automatic, hex-ASCII
M = Manual Setting, ASCII
m = manual, hex-ASCII
Character Mode:
N = Numeric, N data
N, A, B, K A = Alphanumeric, A data
B = Binary , Bnnnn data (where nnnn = data byte-
by data
K = Kanji, K data
The data string is terminated with a termination character,
generally a 0x0d hex, but can be changed by the operator.
[3]
If the Data Input Mode is Automatic, the data string is
terminated with two successive termination characters.
[3]
[2]
Meaning
= Mask 0 to Mask 7
= No Mask
[1]
[2]
[2]
count, 4 decimal digits; byte-count /2 for hex-
ASCII
Class Series 2 Programmer's Manual
(2 termination
characters required.)
[1]
